RL556V3 80% AR15 Lower – OD Green

The RL556V3 80% AR15 Lower in OD Green represents a precision-machined foundation for the custom builder who demands exacting tolerances and material integrity. Designed for the AR-15 platform, this 80% lower receiver is forged from 7075-T6 aluminum and finished with a type III hard coat anodize in olive drab green. The RL556V3 designation indicates a specific generation of the receiver that incorporates reinforced trigger pocket geometry and optimized takedown pin lug clearances, providing a stable platform for both mil-spec and enhanced trigger groups. This component is not a functional firearm and requires additional machining to be completed into a finished receiver.

Overview

The RL556V3 80% AR15 Lower in OD Green is a raw forging that has been precisely profiled to remove 80% of the material required for a fully functional lower receiver. The remaining 20% of work—including trigger pocket milling, safety selector hole drilling, and takedown pin pocket finishing—is left to the end user. The receiver is manufactured from a single piece of 7075-T6 aluminum, heat-treated to MIL-A-8625F specifications, and then hard coat anodized in OD Green for corrosion resistance and colorfastness. The RL556V3 designation specifically refers to the v3 iteration of this lower, which features an enlarged trigger guard for gloved operation and a flared magazine well for faster reloads. The OD Green finish is applied using a type III anodize process that penetrates the aluminum surface, providing a durable coating that resists scratching and wear during handling and assembly.

Features & Specs

• Material: 7075-T6 aluminum forging, heat-treated to MIL-A-8625F standards; finished with type III hard coat anodize in OD Green for impact resistance and UV stability
• Geometry: v3 specification includes reinforced pocket walls (+0.015 inch thickness compared to v2), enlarged trigger guard for use with tactical gloves, and beveled magazine well for easier insertion
• Compatibility: Accepts all mil-spec AR-15 upper receivers, buffer tubes, and trigger groups; uses standard AR-15 magazine catch and bolt catch components

• Precision Tolerances: Trigger pocket machined to +/- 0.002 inch; takedown pin lugs aligned to 0.001 inch concentricity; safety selector hole reamed to 0.250 inch +0.001/-0.000 inch
• Markings: Laser-etched RL556V3 serial number location (blank for user application) and caliber designation area; OD Green anodized finish covers all external surfaces
• Weight: 0.85 pounds (unfinished); overall length: 8.2 inches; width: 1.2 inches; height: 3.5 inches at pistol grip tang

• Finish: Type III hard coat anodize, OD Green per MIL-DTL-5541; tested to 200 hours salt spray resistance; color is consistent across all surfaces including trigger pocket interior
• Included Components: RL556V3 80% lower receiver only; no jig, drill bits, or finishing tools included; packaged in anti-static foam tray to prevent anodize scratching
• Warranty: Manufacturer covers material defects and machining errors in the pre-80% state; does not cover user-induced errors during completion

Who It’s For

This product is intended for experienced builders who possess the necessary tooling—specifically a drill press or CNC router, appropriate end mills, and a finishing jig—to complete the final 20% of machining. The RL556V3 80% AR15 Lower in OD Green is suitable for individuals constructing a customized AR-15 for competition, recreational shooting, or personal defense applications. It is not recommended for first-time builders without prior machining experience, as improper milling can result in an unsafe or non-functional receiver. This component is designed for use by persons legally permitted to own and manufacture firearms under federal and state law. The OD Green finish is particularly suited for builders assembling a rifle with an earth-tone or woodland camouflage color scheme, as it coordinates with most OD Green and coyote brown furniture sets.

Shipping & FFL

This RL556V3 80% AR15 Lower in OD Green is categorized as a non-firearm receiver blank under current ATF regulations. As such, it can be shipped directly to your residential or business address without requiring a Federal Firearms License (FFL) transfer. No background check is required at the time of purchase. However, it is the buyer’s sole responsibility to verify that possession and completion of an 80% lower receiver is legal under all applicable federal, state, and local laws. Some states and municipalities impose restrictions on the purchase, possession, or completion of unserialized receiver blanks. By purchasing this item, you confirm that you are not prohibited from possessing firearms under 18 U.S.C. Section 922(g) and that you will comply with all applicable laws regarding the completion and serialization of this RL556V3 80% AR15 Lower in OD Green. This product ships via UPS Ground or FedEx Ground with adult signature required. International shipping is not available.
